22019 | HELUKABEL
PUR connection cable HELUCONTROL PUR-ORANGE 7 G 1.5 mm², unshielded, orange, 22019
Unit Price (€ / mtr.)
8.6394 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Connecting cable, 22019, HELUKABEL
Robust control and connection cable characterised by high oil resistance, abrasion resistance and notch toughness. Areas of application are machine and tool construction, shipyards, rolling mills and steelworks, construction sites, oil drilling and coal mining. Also often used in plants as a hand tool cable or extension cable.
Features
- Resistant to: oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids, acids, alkalis, greases, seawater and wastewater
- Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant
- For outdoor use
Technical specifications
| Core insulation material | PVC | |
| Colour | orange | |
| Number of cores | 7 | |
| Protective conductor available | Yes | |
| Outer diameter | 11.9 mm | |
| Drag chain suitable | No | |
| Test voltage | 3 kV | |
| Halogen free | No | |
| Cable cross-section | 1.5 mm² | |
| Version | connection line | |
| Material | PUR | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -15 °C to 80 °C | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
