22010 | HELUKABEL
PUR connection cable HELUCONTROL PUR-ORANGE 7 G 1.0 mm², unshielded, orange, 22010
Unit Price (€ / mtr.)
6.4022 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connecting cable, 22010, HELUKABEL
Robust control and connection cable characterised by high oil resistance, abrasion resistance and notch toughness. Areas of application are machine and tool construction, shipyards, rolling mills and steelworks, construction sites, oil drilling and coal mining. Also often used in plants as a hand tool cable or extension cable.
Features
- Resistant to: oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids, acids, alkalis, greases, seawater and wastewater
- Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant
- For outdoor use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Test voltage | 3 kV | |
| Core insulation material | PVC | |
| Protective conductor available | Yes | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -15 °C to 80 °C | |
| Material | PUR | |
| Number of cores | 7 | |
| Cable material | copper, bright | |
| Conductor category | CL.5 = fine stranded | |
| Cable cross-section | 1.0 mm² | |
| Outer diameter | 10.5 mm | |
| Drag chain suitable | No | |
| Halogen free | No | |
| Rated voltage | 500 V | |
| Colour | orange | |
| Shielding | unshielded | |
| Version | connection line |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
