21428 | HELUKABEL
PUR control line Yö-C-PURö-JZ 5 G 0.75 mm², AWG 19, shielded, gray, 21428
Unit Price (€ / mtr.)
5.5097 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 21428, HELUKABEL
The 21428 is a extremely robust control cable characterised by high abrasion and notch resistance properties. Used for critical areas in such applications as machinery, tooling and plant construction, in rolling mills and steel works because of the resistance to mineral oils and to coolant emulsions in particular. The mechanical strength of the cable is increased by the additional oil-resistant inner sheath. The ideal interference-protected control cable for such applications as given above. Suitable for outdoor installation. This screened cable is particularly suitable for the interference-free transmission in instrumentation and control engineering applications (electromagnetic compatibillity).
Features
- Cores stranded in layers with optimal lay lengths
- Core wrapping of fleece guarantees easy cable stripping
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 19 | |
| Colour | gray | |
| Core colour sequence | black | |
| Core insulation material | PVC | |
| Temperature range (active) | -20 °C to 80 °C | |
| Drag chain suitable | No | |
| Rated voltage | 500 V | |
| Halogen free | No | |
| Cable cross-section | 0.75 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Number of cores | 5 | |
| Outer diameter | 9.36 mm | |
| Material | PUR | |
| Test voltage | 4 kV | |
| Product type | control line | |
| Protective conductor available | Yes | |
| Rated voltage U0 | 300 V | |
| Cable material | copper, bright | |
| Shielding | shielded | |
| Conductor category | CL.5 = fine stranded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
