21302 | HELUKABEL
PUR control line F-C-PURö-JZ 4 G 2.5 mm², AWG 14, shielded, gray, 21302
Unit Price (€ / mtr.)
5.8667 € *
Available in 5 Days: 900 mtr. - if ordered today
Control cable, 21302, HELUKABEL
The 21302 is a extremely robust control cable characterised by high abrasion and notch resistance properties. Used for critical areas in such applications as machinery, tooling and plant construction, in rolling mills and steel works because of the resistance to mineral oils and to coolant emulsions in particular. Rapid and safe installation assured by the good flexibility of the cable. Suitable for outdoor installation. An interference-free transmission of signals and pulses is assured by the high screening density. The ideal interference-protected control cable for such applications as given above.
Features
- Cores stranded in layers with optimal lay-length
- Separating foil
- Core wrapping of fleece guarantees easy cable stripping
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core colour sequence | black | |
| Temperature range (active) | -20 °C to 80 °C | |
| Conductor category | CL.5 = fine stranded | |
| Drag chain suitable | No | |
| Cable cross-section | 2.5 mm² | |
| Outer diameter | 9.8 mm | |
| Shielding | shielded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Colour | gray | |
| Number of cores | 4 | |
| Core insulation material | PVC | |
| Test voltage | 3 kV | |
| Rated voltage U0 | 300 V | |
| Protective conductor available | Yes | |
| Material | PUR | |
| Halogen free | No | |
| Rated voltage | 500 V | |
| AWG cross-section | AWG 14 | |
| Version | control line | |
| Cable material | copper, bright |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
