21301 | HELUKABEL
PUR control line F-C-PURö-JZ 3 G 2.5 mm², AWG 14, shielded, gray, 21301
Unit Price (€ / mtr.)
4.6767 € *
Available: 0 mtr.
Available in 5 Days: 100 mtr.
Leadtime: 6 Weeks **
Control cable, 21301, HELUKABEL
The 21301 is a extremely robust control cable characterised by high abrasion and notch resistance properties. Used for critical areas in such applications as machinery, tooling and plant construction, in rolling mills and steel works because of the resistance to mineral oils and to coolant emulsions in particular. Rapid and safe installation assured by the good flexibility of the cable. Suitable for outdoor installation. An interference-free transmission of signals and pulses is assured by the high screening density. The ideal interference-protected control cable for such applications as given above.
Features
- Cores stranded in layers with optimal lay-length
- Separating foil
- Core wrapping of fleece guarantees easy cable stripping
Technical specifications
| Core colour sequence | black | |
| Rated voltage U0 | 300 V | |
| Outer diameter | 9 mm | |
| Test voltage | 3 kV | |
| Drag chain suitable | No | |
| Material | PUR | |
| Shielding | shielded | |
| Temperature range (active) | -20 °C to 80 °C | |
| Core insulation material | PVC | |
| Protective conductor available | Yes | |
| Rated voltage | 500 V | |
| Cable material | copper, bright | |
| Halogen free | No | |
| Number of cores | 3 | |
| Colour | gray | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| AWG cross-section | AWG 14 | |
| Cable cross-section | 2.5 mm² | |
| Conductor category | CL.5 = fine stranded | |
| Version | control line |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
