21281 | HELUKABEL
PUR control line F-C-PURö-JZ 3 G 1.5 mm², AWG 16, shielded, gray, 21281
Unit Price (€ / mtr.)
3.4867 € *
Available in 5 Days: 200 mtr. - if ordered today
Control cable, 21281, HELUKABEL
The 21281 is a extremely robust control cable characterised by high abrasion and notch resistance properties. Used for critical areas in such applications as machinery, tooling and plant construction, in rolling mills and steel works because of the resistance to mineral oils and to coolant emulsions in particular. Rapid and safe installation assured by the good flexibility of the cable. Suitable for outdoor installation. An interference-free transmission of signals and pulses is assured by the high screening density. The ideal interference-protected control cable for such applications as given above.
Features
- Cores stranded in layers with optimal lay-length
- Separating foil
- Core wrapping of fleece guarantees easy cable stripping
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Drag chain suitable | No | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Halogen free | No | |
| Number of cores | 3 | |
| Core insulation material | PVC | |
| Outer diameter | 7.5 mm | |
| Version | control line | |
| Cable material | copper, bright | |
| Temperature range (active) | -20 °C to 80 °C | |
| Rated voltage | 500 V | |
| Protective conductor available | Yes | |
| Test voltage | 3 kV | |
| Material | PUR | |
| Conductor category | CL.5 = fine stranded | |
| AWG cross-section | AWG 16 | |
| Shielding | shielded | |
| Colour | gray | |
| Core colour sequence | black | |
| Rated voltage U0 | 300 V | |
| Cable cross-section | 1.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
