21255 | HELUKABEL
PUR control line F-C-PURö-JZ 4 G 1.0 mm², AWG 18, shielded, gray, 21255
Unit Price (€ / mtr.)
3.2963 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 21255, HELUKABEL
The 21255 is a extremely robust control cable characterised by high abrasion and notch resistance properties. Used for critical areas in such applications as machinery, tooling and plant construction, in rolling mills and steel works because of the resistance to mineral oils and to coolant emulsions in particular. Rapid and safe installation assured by the good flexibility of the cable. Suitable for outdoor installation. An interference-free transmission of signals and pulses is assured by the high screening density. The ideal interference-protected control cable for such applications as given above.
Features
- Cores stranded in layers with optimal lay-length
- Separating foil
- Core wrapping of fleece guarantees easy cable stripping
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 4 | |
| Colour | gray | |
| Cable material | copper, bright | |
| Core insulation material | PVC | |
| Drag chain suitable | No | |
| Test voltage | 3 kV | |
| Cable cross-section | 1.0 mm² | |
| Material | PUR | |
| Shielding | shielded | |
| Protective conductor available | Yes | |
| Outer diameter | 7.4 mm | |
| Temperature range (active) | -20 °C to 80 °C | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Core colour sequence | black | |
| Conductor category | CL.5 = fine stranded | |
| AWG cross-section | AWG 18 | |
| Rated voltage | 500 V | |
| Halogen free | No | |
| Version | control line | |
| Rated voltage U0 | 300 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
