21253 | HELUKABEL

PUR control line F-C-PURö-JZ 2 x 1.0 mm², AWG 18, shielded, gray, 21253

Order No.: 93F6412
EAN: 4060892042492
MPN:
21253
Series: F-C-PURö-JZ
21253 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
2.2967 € *
Available in 5 Days: 600 mtr. - if ordered today
Total Price:
229.67 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
2.2967 €

Control cable, 21253, HELUKABEL

The 21253 is a extremely robust control cable characterised by high abrasion and notch resistance properties. Used for critical areas in such applications as machinery, tooling and plant construction, in rolling mills and steel works because of the resistance to mineral oils and to coolant emulsions in particular. Rapid and safe installation assured by the good flexibility of the cable. Suitable for outdoor installation. An interference-free transmission of signals and pulses is assured by the high screening density. The ideal interference-protected control cable for such applications as given above.

Features

  • Cores stranded in layers with optimal lay-length
  • Separating foil
  • Core wrapping of fleece guarantees easy cable stripping
Technical specifications
Filter Property Value
Material PUR
Cable material copper, bright
Version control line
Conductor category CL.5 = fine stranded
Number of cores 2
Shielding shielded
Core insulation material PVC
Test voltage 3 kV
Cable cross-section 1.0 mm²
Core colour sequence black
Temperature range (unmoved) -40 °C to 80 °C
Temperature range (active) -20 °C to 80 °C
Rated voltage U0 300 V
Drag chain suitable No
Protective conductor available No
Outer diameter 6.5 mm
Colour gray
Rated voltage 500 V
Halogen free No
AWG cross-section AWG 18
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
