21227 | HELUKABEL
PUR control line F-C-PURö-JZ 2 x 0.75 mm², AWG 19, shielded, gray, 21227
Unit Price (€ / mtr.)
1.9754 € *
Available in 5 Days: 100 mtr. - if ordered today
Control cable, 21227, HELUKABEL
The 21227 is a extremely robust control cable characterised by high abrasion and notch resistance properties. Used for critical areas in such applications as machinery, tooling and plant construction, in rolling mills and steel works because of the resistance to mineral oils and to coolant emulsions in particular. Rapid and safe installation assured by the good flexibility of the cable. Suitable for outdoor installation. An interference-free transmission of signals and pulses is assured by the high screening density. The ideal interference-protected control cable for such applications as given above.
Features
- Cores stranded in layers with optimal lay-length
- Separating foil
- Core wrapping of fleece guarantees easy cable stripping
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Protective conductor available | No | |
| Cable cross-section | 0.75 mm² | |
| Temperature range (active) | -20 °C to 80 °C | |
| Number of cores | 2 | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Test voltage | 3 kV | |
| Rated voltage | 500 V | |
| Core colour sequence | black | |
| Drag chain suitable | No | |
| Cable material | copper, bright | |
| Core insulation material | PVC | |
| AWG cross-section | AWG 19 | |
| Version | control line | |
| Material | PUR | |
| Rated voltage U0 | 300 V | |
| Halogen free | No | |
| Conductor category | CL.5 = fine stranded | |
| Colour | gray | |
| Outer diameter | 6.1 mm | |
| Shielding | shielded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
