20018 | HELUKABEL
PVC control line TRONIC-CY (LiY-CY) 32 x 0.14 mm², AWG 26, shielded, gray, 20018
Unit Price (€ / mtr.)
3.3320 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
333.20 € *
Price list
Quantity
Price per unit*
100 mtr.
3.3320 €
500 mtr.
3.1178 €
*incl. VAT plus shipping costs
Subject to prior sale
PVC Control cable, 20018, HELUKABEL
These screened cables are used for flexible use with free movement without tensile stress or forced movements in dry, moist and wet rooms but not suitable for open air, wherever the construction requirements call for a minimum outer diameter, TRONIC is the suitable cable to use. This applies especially to such areas as tool making and machine industries as well as electronic, computer, measurement and control sectors.
FEATURES
- Good chemical resistance
- Oil-resistant
- Flame-retardant
- Cadmium-free
Technical Data
- Cable material: Copper, bright
- Test voltage: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Core insulation material | PVC | |
| Colour | gray | |
| Number of cores | 32 | |
| Protective conductor available | No | |
| Outer diameter | 9.9 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 26 | |
| Test voltage | 1.2 kV | |
| Halogen free | No | |
| Cable cross-section | 0.14 mm² | |
| Version | control line | |
| Material | PVC | |
| Cable material | copper, bright | |
| Shielding | shielded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -5 °C to 80 °C | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 350 V |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
