18453 | HELUKABEL

PUR connection and control cable UNIPUR 3 G 1.5 mm², AWG 16, unshielded, yellow, 18453

Order No.: 93F9039
EAN: 4060892067723
MPN:
18453
Series: UNIPUR
18453 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
4.4863 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
448.63 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
4.4863 €

Connection cable, 18453, HELUKABEL

The 18453 is a robust, flexible cable for use in dry, damp and wet rooms, as well as outdoors. 0.5-1 mm²: for connecting devices with light mechanical stress in households and offices (e.g. portable household appliances, hand lamps). 1.5-16 mm²: for connecting devices with medium mechanical stress in commercial and agricultural workshops (e.g. power tools such as drills, circular saws). When installed in pipes or similar closed systems, the cable is permitted for use up to and including 1000 V alternating voltage or 750 V direct voltage to earth.

Features

  • Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion
  • For outdoor use
  • Flexible in cold temperatures
  • Halogen-free
Technical specifications
Core insulation material TPE
Colour yellow
Number of cores 3
Protective conductor available Yes
Outer diameter 8.6 mm
Drag chain suitable No
AWG cross-section AWG 16
Test voltage 3 kV
Halogen free Yes
Cable cross-section 1.5 mm²
Version connection line
Material PUR
Cable material copper, bright
Shielding unshielded
Rated voltage U0 450 V
Temperature range (active) -40 °C to 90 °C
Conductor category CL.5 = fine stranded
Rated voltage 750 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
