PUR connection and control cable UNIPUR 4 G 1.0 mm², AWG 18, unshielded, gray, 18357
Unit Price (€ / mtr.)
2.9631 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connection cable, 18357, HELUKABEL
The 18357 is a robust, flexible cable for use in dry, damp and wet rooms, as well as outdoors. 0.5-1 mm²: for connecting devices with light mechanical stress in households and offices (e.g. portable household appliances, hand lamps). 1.5-16 mm²: for connecting devices with medium mechanical stress in commercial and agricultural workshops (e.g. power tools such as drills, circular saws). When installed in pipes or similar closed systems, the cable is permitted for use up to and including 1000 V alternating voltage or 750 V direct voltage to earth.
Features
- Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion
- For outdoor use
- Flexible in cold temperatures
- Halogen-free
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage U0 | 300 V | |
| Colour | gray | |
| Outer diameter | 7.9 mm | |
| Drag chain suitable | No | |
| Protective conductor available | Yes | |
| AWG cross-section | AWG 18 | |
| Number of cores | 4 | |
| Core insulation material | TPE | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| Material | PUR | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Product type | connection and control cable | |
| Test voltage | 3 kV | |
| Cable cross-section | 1.0 mm² | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (active) | -40 °C to 90 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
