18333 | HELUKABEL
PUR connection and control cable UNIPUR 2 x 1.0 mm², AWG 18, unshielded, yellow, 18333
Unit Price (€ / mtr.)
1.8683 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connection cable, 18333, HELUKABEL
The 18333 is a robust, flexible cable for use in dry, damp and wet rooms, as well as outdoors. 0.5-1 mm²: for connecting devices with light mechanical stress in households and offices (e.g. portable household appliances, hand lamps). 1.5-16 mm²: for connecting devices with medium mechanical stress in commercial and agricultural workshops (e.g. power tools such as drills, circular saws). When installed in pipes or similar closed systems, the cable is permitted for use up to and including 1000 V alternating voltage or 750 V direct voltage to earth.
Features
- Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion
- For outdoor use
- Flexible in cold temperatures
- Halogen-free
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable cross-section | 1.0 mm² | |
| Core insulation material | TPE | |
| Drag chain suitable | No | |
| Protective conductor available | No | |
| Outer diameter | 6.6 mm | |
| Material | PUR | |
| Rated voltage U0 | 300 V | |
| Colour | yellow | |
| Test voltage | 3 kV | |
| Version | connection line | |
| Number of cores | 2 | |
| Temperature range (active) | -40 °C to 90 °C | |
| Shielding | unshielded | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| AWG cross-section | AWG 18 | |
| Cable material | copper, bright |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
