16424 | HELUKABEL

PVC control line F-CY-JZ 4 G 4.0 mm², AWG 12, shielded, gray, 16424

Order No.: 93F1698
EAN: 4099891242688
MPN:
16424
Series: F-CY-JZ
16424 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
5.5216 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
552.16 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
5.5216 €

PVC Control cable, 16424, HELUKABEL

For use as a data cable in control circuits, in tool-making and machine industries as well as a signal cable in computer systems and electronics. The more usual PVC inner sheath has been replaced in these cables by a stabilising foil separator, thus reducing the total diameter of the cables considerably and thereby reducing the bending radius, total weight etc.

FEATURES

  • Good chemical resistance
  • Flame-retardant
  • Oil-resistant
  • Flame-retardant

Technical Data

  • Cable material: Copper, bright
  • Test voltage: PVC
  • Color: gray
  • Conductor category: Cl.5 = fine-stranded
Technical specifications
Temperature range (active) -10 °C to 80 °C
Protective conductor available Yes
Number of cores 4
Halogen free No
Material PVC
Standard number VDE
Colour gray
AWG cross-section AWG 12
Outer diameter 12.3 mm
Rated voltage 500 V
Test voltage 4 kV
Cable material copper, bright
Core insulation material PVC
Core colour sequence black
Conductor category CL.5 = fine stranded
Version control line
Temperature range (unmoved) -40 °C to 80 °C
Shielding shielded
Drag chain suitable No
Cable cross-section 4.0 mm²
Rated voltage U0 300 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
