16155 | HELUKABEL
PVC control line Y-CY-JB 5 x 25 mm², AWG 4, shielded, transparent, 16155
Unit Price (€ / mtr.)
42.0546 € *
Standard delivery time from the manufacturer is: 6 Weeks
PVC Control cable, 16155, HELUKABEL
For use as a data and control cable in machinery, computer systems etc. as well as a signal cable for electronics. The high level of screening ensures a high degree of interference protection. The screening density assures disturbance-free transmission of all signals and impulses. The PVC-inner sheaths of those cables raise the mechanical stress.
FEATURES
- Good chemical resistance
- Oil-resistant
- Cadmium-free
- Flame-retardant
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: transparent
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | PVC | |
| Colour | transparent | |
| Number of cores | 5 | |
| Protective conductor available | No | |
| Outer diameter | 34.9 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 4 | |
| Test voltage | 4 kV | |
| Halogen free | No | |
| Cable cross-section | 25 mm² | |
| Version | control line | |
| Material | PVC | |
| Cable material | copper, bright | |
| Shielding | shielded | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -15 °C to 80 °C | |
| Conductor category | CL.5 = fine stranded | |
| Standard number | VDE | |
| Rated voltage | 500 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
