15980 | HELUKABEL
PVC control line JZ-HF-CY 7 G 1.5 mm², AWG 16, shielded, gray, 15980
Unit Price (€ / mtr.)
6.2237 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 15980, HELUKABEL
The 15980 is a control cable used for installation in dry and damp rooms, but not outdoors. With free movement, without tensile stress and without forced motion control capabilities, this cable has proven it's reliable per-formance in standard drag chain applications, automatic handling machines, robots and permanently moving machine parts. This screened cable has been developed for interference-free data signal transmission for all areas in electronics, measurement and control technology.
Features
- Cores stranded in layers with optimally matched lay lengths
- Fleece wrapping over each stranding layer
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 16 | |
| Core insulation material | PVC | |
| Temperature range (active) | -10 °C to 80 °C | |
| Test voltage | 4 kV | |
| Colour | gray | |
| Halogen free | No | |
| Number of cores | 7 | |
| Shielding | shielded | |
| Outer diameter | 12.8 mm | |
| Conductor category | CL.6 = finest stranded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Material | PVC | |
| Rated voltage U0 | 300 V | |
| Protective conductor available | Yes | |
| Rated voltage | 500 V | |
| Drag chain suitable | Yes | |
| Core colour sequence | black | |
| Product type | control line | |
| Cable material | copper, bright | |
| Cable cross-section | 1.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
