15962 | HELUKABEL
PVC control line JZ-HF-CY 3 G 1.0 mm², AWG 18, shielded, gray, 15962
Unit Price (€ / mtr.)
3.4034 € *
Available in 5 Days: 500 mtr. - if ordered today
Drag chain cable, 15962, HELUKABEL
The 15962 is a PVC drag chain cable Used for installation in dry and damp rooms, but not outdoors. With free movement, without tensile stress and without forced motion control capabilities, these cables have proven their reliable performance in standard drag chain applications, automatic handling machines, robots and permanently moving machine parts. This screened cable has been developed for interference-free data signal transmission for all areas in electronics, measurement and control technology.
Features
- Oil resistant
- With PVC inner sheath
- EMC-preferred type
- For use in drag chains in continuous motion
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.6 = finest stranded | |
| Number of cores | 3 | |
| Shielding | shielded | |
| Core insulation material | PVC | |
| Test voltage | 4 kV | |
| Cable cross-section | 1.0 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -10 °C to 80 °C | |
| Rated voltage U0 | 300 V | |
| Drag chain suitable | Yes | |
| Protective conductor available | Yes | |
| Outer diameter | 8.5 mm | |
| Colour | gray | |
| Rated voltage | 500 V | |
| Halogen free | No | |
| AWG cross-section | AWG 18 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
