15947 | HELUKABEL
PVC control line JZ-HF-CY 4 G 0.75 mm², AWG 19, shielded, gray, 15947
Unit Price (€ / mtr.)
3.3439 € *
Available in 5 Days: 500 mtr. - if ordered today
Control cable, 15947, HELUKABEL
The 15947 is a control cable used for installation in dry and damp rooms, but not outdoors. With free movement, without tensile stress and without forced motion control capabilities, this cable has proven it's reliable per-formance in standard drag chain applications, automatic handling machines, robots and permanently moving machine parts. This screened cable has been developed for interference-free data signal transmission for all areas in electronics, measurement and control technology.
Features
- Cores stranded in layers with optimally matched lay lengths
- Fleece wrapping over each stranding layer
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | No | |
| Shielding | shielded | |
| Test voltage | 4 kV | |
| Colour | gray | |
| Drag chain suitable | Yes | |
| Rated voltage U0 | 300 V | |
| Outer diameter | 8.7 mm | |
| Protective conductor available | Yes | |
| Core insulation material | PVC | |
| Temperature range (active) | -10 °C to 80 °C | |
| Number of cores | 4 | |
| Cable material | copper, bright | |
| AWG cross-section | AWG 19 | |
| Material | PVC | |
| Core colour sequence | black | |
| Rated voltage | 500 V | |
| Version | control line | |
| Conductor category | CL.6 = finest stranded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Cable cross-section | 0.75 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
