15933 | HELUKABEL
PVC control line JZ-HF-CY 5 G 0.5 mm², AWG 20, shielded, gray, 15933
Unit Price (€ / mtr.)
3.5343 € *
Available in 5 Days: 300 mtr. - if ordered today
Control cable, 15933, HELUKABEL
The 15933 is a control cable used for installation in dry and damp rooms, but not outdoors. With free movement, without tensile stress and without forced motion control capabilities, this cable has proven it's reliable per-formance in standard drag chain applications, automatic handling machines, robots and permanently moving machine parts. This screened cable has been developed for interference-free data signal transmission for all areas in electronics, measurement and control technology.
Features
- Cores stranded in layers with optimally matched lay lengths
- Fleece wrapping over each stranding layer
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Conductor category | CL.6 = finest stranded | |
| Core insulation material | PVC | |
| Rated voltage U0 | 300 V | |
| Halogen free | No | |
| Outer diameter | 8.6 mm | |
| Material | PVC | |
| Number of cores | 5 | |
| Test voltage | 4 kV | |
| Rated voltage | 500 V | |
| Cable material | copper, bright | |
| Cable cross-section | 0.5 mm² | |
| Protective conductor available | Yes | |
| Colour | gray | |
| Temperature range (active) | -10 °C to 80 °C | |
| Shielding | shielded | |
| Core colour sequence | black | |
| Version | control line | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| AWG cross-section | AWG 20 | |
| Drag chain suitable | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
