15009 | HELUKABEL
PVC control line JZ-HF 16 G 0.5 mm², AWG 20, unshielded, gray, 15009
Unit Price (€ / mtr.)
5.1408 € *
Available in 5 Days: 500 mtr. - if ordered today
Control cable, 15009, HELUKABEL
JZ-HF cables are ideal for use in the machine tool industry, in robotics and machine production and anywhere where high flexibility is essential. These cables have shown excellent performance in combination with standard cable trays. These cables are suitable for flexible use for medium mechanical stresses with free movements.
FEATURES
- Good chemical resistance
- Abrasion-resistant
- Oil-resistant
- Flame-retardant
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable material | copper, bright | |
| Core insulation material | PVC | |
| Protective conductor available | Yes | |
| Temperature range (active) | -10 °C to 80 °C | |
| Version | control line | |
| Number of cores | 16 | |
| Standard number | VDE | |
| Rated voltage U0 | 300 V | |
| Conductor category | CL.5 = fine stranded | |
| Halogen free | No | |
| Drag chain suitable | Yes | |
| Shielding | unshielded | |
| AWG cross-section | AWG 20 | |
| Cable cross-section | 0.5 mm² | |
| Core colour sequence | black | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Outer diameter | 10.3 mm | |
| Colour | gray | |
| Test voltage | 4 kV | |
| Material | PVC | |
| Rated voltage | 500 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
