14035 | HELUKABEL
PVC connection cable OZ-BL-CY 18 x 0.75 mm², shielded, blue, 14035
Unit Price (€ / mtr.)
7.7707 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connecting cable, 14035, HELUKABEL
PVC control cable used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control. For explosion-endangered areas marked as intrinsically safe (blue) (ignition protection type -i-) flexible control or measurement cable for intrinsically safe systems in measurement and control technology.
Features
- Resistant to: UV radiation, weathering effects
- Largely resistant to oil
- For outdoor use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | PVC | |
| Colour | blue | |
| Number of cores | 18 | |
| Protective conductor available | No | |
| Outer diameter | 12.9 mm | |
| Drag chain suitable | No | |
| Test voltage | 3 kV | |
| Halogen free | No | |
| Core colour sequence | black | |
| Cable cross-section | 0.75 mm² | |
| Version | connection line | |
| Material | PVC | |
| Cable material | copper, bright | |
| Shielding | shielded | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -10 °C to 80 °C | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
