13066 | HELUKABEL

PVC connection cable H05VVC4V5-K 12 G 0.5 mm², AWG 20, shielded, gray, 13066

Order No.: 93F6612
EAN: 4060892028601
MPN:
13066
Series: H05VVC4V5-K
13066 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
5.0337 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
503.37 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
5.0337 €

Control cable, 13066, HELUKABEL

The 13066 is a PVC control cable Used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use as a connection cable in machine and machine tool construction, assembly lines, conveyers and production lines. Even various chemical compounds cannot harm the cable. As a cable suitable for damp rooms, it is also preferred for the operation of machines in breweries, bottling plants and car washes. For interference-free data signal transmission in measurement and control technology in case electromagnetic screening is required. The cable may engage in flexible movement after installation, provided the cable is not mechanically overloaded during the movements. This shielded cable is not designed for permanent bending stresses.

Technical specifications
Core insulation material PVC
Colour gray
Number of cores 12
Protective conductor available Yes
Outer diameter 16.5 mm
Drag chain suitable No
AWG cross-section AWG 20
Test voltage 2 kV
Halogen free No
Cable cross-section 0.5 mm²
Version connection line
Material PVC
Cable material copper, bright
Shielding shielded
Rated voltage U0 300 V
Temperature range (unmoved) -40 °C to 70 °C
Temperature range (active) -5 °C to 70 °C
Conductor category CL.5 = fine stranded
Rated voltage 500 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
