12767 | HELUKABEL
Polymer connection cable JZ-600 HMH 10 G 1.5 mm², AWG 16, unshielded, black, 12767
Unit Price (€ / mtr.)
7.4851 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connection cable, 12767, HELUKABEL
The 12767 is a connection cable in tool machinery, conveyor belts, production lines, plant construction, in air-conditioning devices, in metallurgical, steel and rolling mills. For fixed installation and flexible applications with occasional, not constantly recurring free movement without forced motion, without tensile stress and for medium mechanical stress. The cable is suitable for use in dry, damp and wet locations, outdoors (fixed installation) and on plaster.
Features
- Highly flame-retardant
- Resistant to UV radiation, weathering effects
- Largely oil resistant
- For outdoor use
- Halogen-free
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | polymer | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Number of cores | 10 | |
| Shielding | unshielded | |
| Core insulation material | polymer | |
| Test voltage | 4 kV | |
| Cable cross-section | 1.5 mm² | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -25 °C to 70 °C | |
| Rated voltage U0 | 600 V | |
| Drag chain suitable | No | |
| Protective conductor available | Yes | |
| Outer diameter | 15.2 mm | |
| Colour | black | |
| Rated voltage | 1 kV | |
| Halogen free | Yes | |
| AWG cross-section | AWG 16 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
