12756 | HELUKABEL
Polymer connection cable JZ-600 HMH 12 G 1.0 mm², AWG 18, unshielded, black, 12756
Unit Price (€ / mtr.)
5.8429 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connection cable, 12756, HELUKABEL
The 12756 is a connection cable in tool machinery, conveyor belts, production lines, plant construction, in air-conditioning devices, in metallurgical, steel and rolling mills. For fixed installation and flexible applications with occasional, not constantly recurring free movement without forced motion, without tensile stress and for medium mechanical stress. The cable is suitable for use in dry, damp and wet locations, outdoors (fixed installation) and on plaster.
Features
- Highly flame-retardant
- Resistant to UV radiation, weathering effects
- Largely oil resistant
- For outdoor use
- Halogen-free
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 18 | |
| Core insulation material | polymer | |
| Temperature range (active) | -25 °C to 70 °C | |
| Test voltage | 4 kV | |
| Colour | black | |
| Halogen free | Yes | |
| Number of cores | 12 | |
| Shielding | unshielded | |
| Outer diameter | 13.2 mm | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Material | polymer | |
| Rated voltage U0 | 600 V | |
| Protective conductor available | Yes | |
| Rated voltage | 1 kV | |
| Drag chain suitable | No | |
| Product type | connection cable | |
| Cable material | copper, bright | |
| Cable cross-section | 1.0 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
