12473 | HELUKABEL
PUR control line JZ-602-PUR 4 G 0.5 mm², AWG 20, unshielded, gray, 12473
Unit Price (€ / mtr.)
3.4272 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Connection cable, 12473, HELUKABEL
UL and CSA approved flexible control cable rated at 600 V, primarily designed for exporters to the US or Canadian market. Used in machine tools, control systems, connection between control panels and machines, assembly lines and other industrial equipment. Suitable for installation in dry, moist, wet and outdoor environment and moderate flexing applications.
Features
- Resistant to oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids, acids, alkalis, greases, seawater and wastewater
- Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion
- For outdoor use
Technical specifications
| Core insulation material | PVC | |
| Colour | gray | |
| Number of cores | 4 | |
| Protective conductor available | Yes | |
| Outer diameter | 6.6 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 20 | |
| Test voltage | 3 kV | |
| Rated voltage UL/CSA | 600 V | |
| Halogen free | No | |
| Cable cross-section | 0.5 mm² | |
| Version | control line | |
| Material | PUR | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -5 °C to 80 °C | |
| Conductor category | CL.5 = fine stranded |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
