12078 | HELUKABEL
PVC control line SY-JZ 3 G 2.5 mm², AWG 14, shielded, transparent, 12078
Unit Price (€ / mtr.)
3.9627 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 12078, HELUKABEL
This is used as a connection and control cable for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use in machine tools, plant construction and data technology. Due to the dense braiding, the cable is well protected against mechanical damage. The galvanisation of the braid prevents corrosion and guarantees improved solderability of the braid.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 3 | |
| Rated voltage U0 | 300 V | |
| Rated voltage | 500 V | |
| Version | control line | |
| Cable cross-section | 2.5 mm² | |
| Test voltage | 4 kV | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Protective conductor available | Yes | |
| Cable material | copper, bright | |
| Material | PVC | |
| Outer diameter | 11.1 mm | |
| AWG cross-section | AWG 14 | |
| Drag chain suitable | No | |
| Core insulation material | PVC | |
| Colour | transparent | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (active) | -15 °C to 80 °C | |
| Shielding | shielded | |
| Core colour sequence | black | |
| Halogen free | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
