12038 | HELUKABEL
PVC control line SY-JZ 5 G 1.0 mm², AWG 18, shielded, transparent, 12038
Unit Price (€ / mtr.)
3.2963 € *
Available: 0 mtr.
Available in 5 Days: 100 mtr.
Leadtime: 6 Weeks **
Control cable, 12038, HELUKABEL
This is used as a connection and control cable for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use in machine tools, plant construction and data technology. Due to the dense braiding, the cable is well protected against mechanical damage. The galvanisation of the braid prevents corrosion and guarantees improved solderability of the braid.
Technical specifications
| Colour | transparent | |
| Shielding | shielded | |
| Temperature range (active) | -15 °C to 80 °C | |
| Protective conductor available | Yes | |
| AWG cross-section | AWG 18 | |
| Rated voltage U0 | 300 V | |
| Drag chain suitable | No | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Test voltage | 4 kV | |
| Material | PVC | |
| Cable material | copper, bright | |
| Core colour sequence | black | |
| Cable cross-section | 1.0 mm² | |
| Rated voltage | 500 V | |
| Core insulation material | PVC | |
| Conductor category | CL.5 = fine stranded | |
| Outer diameter | 10.1 mm | |
| Halogen free | No | |
| Version | control line | |
| Number of cores | 5 |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
