11967 | HELUKABEL

FRNC control line JB-750 HMH 5 x 1.5 mm², AWG 16, unshielded, gray, 11967

Order No.: 93F6358
EAN: 4060892049682
MPN:
11967
Series: JB-750 HMH
11967 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
3.9508 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
395.08 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
3.9508 €

Control cable, 11967, HELUKABEL

The 11967 halogen-free, flame retardant cable is used as measuring and control cable in machine tools, conveyor belts, production lines as well as in plant installations, in air-conditioning and steel production works. For fixed installation or flexible application, directed without forcing by casual, not constantly recurring free movements and without tensile stress, for medium mechanical strain. This cable is suitable for the application in dry, damp and wet environments and also for laying on plaster.

Features

  • Core insulation of halogen-free polymer compound type TI6 to DIN VDE 0207-363-7 / DIN EN 50363-7
  • Cores stranded in layers with optimal lay-length
  • Outer sheath of halogen-free polymer compound type TM7 to DIN VDE 0207-363-8 / DIN EN 50363-8
  • Low Smoke Zero Halogen
Technical specifications
Colour gray
Number of cores 5
Outer diameter 9.6 mm
Drag chain suitable No
AWG cross-section AWG 16
Test voltage 3 kV
Halogen free Yes
Cable cross-section 1.5 mm²
Version control line
Material FRNC
Cable material copper, bright
Shielding unshielded
Rated voltage U0 450 V
Temperature range (unmoved) -40 °C to 70 °C
Temperature range (active) -15 °C to 70 °C
Conductor category CL.5 = fine stranded
Rated voltage 750 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
