11965 | HELUKABEL
FRNC control line JB-750 HMH 3 x 1.5 mm², AWG 16, unshielded, gray, 11965
Unit Price (€ / mtr.)
2.3562 € *
Available in 5 Days: 1,500 mtr. - if ordered today
Control cable, 11965, HELUKABEL
The 11965 halogen-free, flame retardant cable is used as measuring and control cable in machine tools, conveyor belts, production lines as well as in plant installations, in air-conditioning and steel production works. For fixed installation or flexible application, directed without forcing by casual, not constantly recurring free movements and without tensile stress, for medium mechanical strain. This cable is suitable for the application in dry, damp and wet environments and also for laying on plaster.
Features
- Core insulation of halogen-free polymer compound type TI6 to DIN VDE 0207-363-7 / DIN EN 50363-7
- Cores stranded in layers with optimal lay-length
- Outer sheath of halogen-free polymer compound type TM7 to DIN VDE 0207-363-8 / DIN EN 50363-8
- Low Smoke Zero Halogen
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable material | copper, bright | |
| Test voltage | 3 kV | |
| Conductor category | CL.5 = fine stranded | |
| Material | FRNC | |
| Version | control line | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -15 °C to 70 °C | |
| Rated voltage U0 | 450 V | |
| Halogen free | Yes | |
| Outer diameter | 7.8 mm | |
| AWG cross-section | AWG 16 | |
| Drag chain suitable | No | |
| Colour | gray | |
| Number of cores | 3 | |
| Rated voltage | 750 V | |
| Shielding | unshielded | |
| Cable cross-section | 1.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
