11793 | HELUKABEL
Polymer control line JZ-500 HMH-C 4 G 16 mm², AWG 6, shielded, gray, 11793
Unit Price (€ / mtr.)
24.7877 € *
Standard delivery time from the manufacturer is: 6 Weeks
PVC Control cable, 11793, HELUKABEL
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines, conveyor belts, assembly lines, plant engineering, AC technology, steel production and other manufacturing environments.
FEATURES
- Good chemical resistance
- Power Chain
- Oil-resistant
- Halogen-free
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage | 500 V | |
| Material | polymer | |
| Shielding | shielded | |
| Version | control line | |
| Core colour sequence | black | |
| Temperature range (active) | -15 °C to 70 °C | |
| Protective conductor available | Yes | |
| Conductor category | CL.5 = fine stranded | |
| Halogen free | Yes | |
| Outer diameter | 20.4 mm | |
| Colour | gray | |
| Drag chain suitable | No | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| AWG cross-section | AWG 6 | |
| Cable material | copper, bright | |
| Number of cores | 4 | |
| Core insulation material | polymer | |
| Rated voltage U0 | 300 V | |
| Test voltage | 4 kV | |
| Cable cross-section | 16 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
