11547 | HELUKABEL

PVC control line JZ-600-Y-CY 3 G 1.5 mm², AWG 16, shielded, black, 11547

Order No.: 93F643
EAN: 4099891259471
MPN:
11547
Series: JZ-600-Y-CY
11547 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
3.0940 € *
Available: 0 mtr.
Available in 5 Days: 400 mtr.
Leadtime: 6 Weeks **
Total Price:
309.40 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
3.0940 €

Control cable, 11547, HELUKABEL

Wiring cable for measuring and controlling purposes in tool machinery, conveyor belts and production lines, for plant installations, air conditioning and in steel production plants and rolling mills. Suitable for installation for flexible use for medium mechanical stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms as well as outside (fixed installation). Is not suitable to be used as direct burria (suitable from an outer diameter of 18,0 mm for direct burial) or as underwater cable.

FEATURES

  • Good chemical resistance
  • Flame-retardant
  • Oil-resistant
  • UV-resistant

Technical Data

  • Cable material: Copper, bright
  • Test voltage: 4000 V
  • Color: black
  • Conductor category: Cl.5 = fine-stranded
Technical specifications
Core insulation material PVC
Colour black
Number of cores 3
Protective conductor available Yes
Outer diameter 11.3 mm
Drag chain suitable No
AWG cross-section AWG 16
Test voltage 4 kV
Halogen free No
Core colour sequence black
Cable cross-section 1.5 mm²
Version control line
Material PVC
Cable material copper, bright
Shielding shielded
Rated voltage U0 600 V
Temperature range (unmoved) -40 °C to 80 °C
Temperature range (active) -15 °C to 80 °C
Conductor category CL.5 = fine stranded
Rated voltage 1 kV
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
