11339 | HELUKABEL
Polymer control line JZ-500 HMH 3 x 1.0 mm², AWG 18, unshielded, gray, 11339
Unit Price (€ / mtr.)
1.4875 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 10107, HELUKABEL
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines, conveyor belts, assembly lines, plant engineering, AC technology, steel production and other manufacturing environments.
FEATURES
- Good chemical resistance
- Power Chain
- Oil-resistant
- Cadmium-free
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 18 | |
| Colour | gray | |
| Core colour sequence | black | |
| Core insulation material | polymer | |
| Temperature range (active) | -15 °C to 70 °C | |
| Drag chain suitable | No | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| Cable cross-section | 1.0 mm² | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Number of cores | 3 | |
| Outer diameter | 6.1 mm | |
| Material | polymer | |
| Test voltage | 4 kV | |
| Product type | control line | |
| Protective conductor available | No | |
| Rated voltage U0 | 300 V | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Conductor category | CL.5 = fine stranded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
