11290 | HELUKABEL
Polymer control line JZ-500 HMH 2 x 4.0 mm², AWG 12, unshielded, gray, 11290
Unit Price (€ / mtr.)
3.5700 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 10101, HELUKABEL
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines, conveyor belts, assembly lines, plant engineering, AC technology, steel production and other manufacturing environments.
FEATURES
- Good chemical resistance
- Power Chain
- Oil-resistant
- Cadmium-free
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | polymer | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Number of cores | 2 | |
| Shielding | unshielded | |
| Core insulation material | polymer | |
| Test voltage | 4 kV | |
| Cable cross-section | 4.0 mm² | |
| Core colour sequence | black | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -15 °C to 70 °C | |
| Rated voltage U0 | 300 V | |
| Drag chain suitable | No | |
| Protective conductor available | No | |
| Outer diameter | 9.2 mm | |
| Colour | gray | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| AWG cross-section | AWG 12 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
