11221 | HELUKABEL
Polymer control line JZ-500 HMH 2 x 0.75 mm², AWG 19, unshielded, gray, 11221
Unit Price (€ / mtr.)
0.8568 € *
Available in 5 Days: 300 mtr. - if ordered today
Control cable, 10095, HELUKABEL
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines, conveyor belts, assembly lines, plant engineering, AC technology, steel production and other manufacturing environments.
FEATURES
- Good chemical resistance
- Power Chain
- Oil-resistant
- Cadmium-free
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Outer diameter | 5.3 mm | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| Material | polymer | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Core colour sequence | black | |
| Version | control line | |
| Number of cores | 2 | |
| Core insulation material | polymer | |
| Protective conductor available | No | |
| AWG cross-section | AWG 19 | |
| Temperature range (active) | -15 °C to 70 °C | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Colour | gray | |
| Cable cross-section | 0.75 mm² | |
| Drag chain suitable | No | |
| Conductor category | CL.5 = fine stranded | |
| Test voltage | 4 kV |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
