11164 | HELUKABEL
PVC control line JB-750 4 G 2.5 mm², AWG 14, unshielded, gray, 11164
Unit Price (€ / mtr.)
3.1416 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 11164, HELUKABEL
These cables are used for flexible use for medium mechanical stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms but not suitable for open air, as measuring and control cables in tool machinery, conveyor belts, production lines, as well as in machinery production, in air-conditioning and steel production plants.
FEATURES
- Good chemical resistance
- Oil-resistant
- Cadmium-free
- Flame-retardant
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Protective conductor available | Yes | |
| Cable cross-section | 2.5 mm² | |
| Outer diameter | 10.2 mm | |
| Version | control line | |
| Temperature range (active) | -15 °C to 80 °C | |
| Rated voltage U0 | 450 V | |
| Number of cores | 4 | |
| Colour | gray | |
| AWG cross-section | AWG 14 | |
| Material | PVC | |
| Cable material | copper, bright | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Test voltage | 4 kV | |
| Core insulation material | PVC | |
| Rated voltage | 750 V | |
| Halogen free | No | |
| Shielding | unshielded | |
| Drag chain suitable | No | |
| Conductor category | CL.5 = fine stranded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
