11009 | HELUKABEL
PVC control line JB-500 7 G 0.5 mm², AWG 20, unshielded, gray, 11009
Unit Price (€ / mtr.)
1.3328 € *
Standard delivery time from the manufacturer is: 6 Weeks
PVC Control cable, 11009, HELUKABEL
For flexible use under medium mechanical stress with free movement without tensile stress and without forced motion control in dry, moist and wet rooms but not suitable for open air as measuring and control cables in machine tools, conveyor belts, production lines, as well as plant engineering, heating and air conditioning.
FEATURES
- Good chemical resistance
- Oil-resistant
- Cadmium-free
- Flame-retardant
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | No | |
| Shielding | unshielded | |
| Test voltage | 4 kV | |
| Colour | gray | |
| Drag chain suitable | Yes | |
| Rated voltage U0 | 300 V | |
| Outer diameter | 6.7 mm | |
| Protective conductor available | Yes | |
| Core insulation material | PVC | |
| Temperature range (active) | -15 °C to 80 °C | |
| Number of cores | 7 | |
| Cable material | copper, bright | |
| AWG cross-section | AWG 20 | |
| Material | PVC | |
| Rated voltage | 500 V | |
| Standard number | VDE | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Cable cross-section | 0.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
