10954 | HELUKABEL
PVC connection cable JZ-500-C black 7 G 1.0 mm², AWG 18, shielded, black, 10954
Unit Price (€ / mtr.)
4.1412 € *
Available in 5 Days: 200 mtr. - if ordered today
Connection cable, 10954, HELUKABEL
The 10954 is a connection cable used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, as well as outdoors. Used as a connection and control cable in machine and plant construction, in machine tools, production lines, assembly lines and conveyor belts.
Features
- UV resistant
- For outdoor use
- EMC-preferred type
- Largely oil resistant
- Versatile use in many industries, particularly in machine and plant construction
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Temperature range (active) | -10 °C to 80 °C | |
| Colour | black | |
| Cable material | copper, bright | |
| Drag chain suitable | No | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Core insulation material | PVC | |
| Rated voltage | 500 V | |
| Outer diameter | 9 mm | |
| Shielding | shielded | |
| Number of cores | 7 | |
| Cable cross-section | 1.0 mm² | |
| Protective conductor available | Yes | |
| Test voltage | 4 kV | |
| Rated voltage U0 | 300 V | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Material | PVC | |
| AWG cross-section | AWG 18 | |
| Halogen free | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
