10882 | HELUKABEL
Connection cable Single 600-O 1 x 6.0 mm², AWG 10, black, 10882
Unit Price (€ / mtr.)
3.5700 € *
Available: 100 mtr.
Total Price:
3.57 € *
Price list
Quantity
Price per unit*
1 mtr.
3.5700 €
10 mtr.
3.2844 €
50 mtr.
3.0821 €
100 mtr.
2.8917 €
*incl. VAT plus shipping costs
Subject to prior sale
PVC sheathed single core, 10882, HELUKABEL
The 10882 is a PVC sheathed single core cable suitable for medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, as well as outdoors. May not be laid directly in soil or water. This two-standard sheathed single core cables are preferably used in export-oriented mechanical engineering on machine tools, production lines and in plant construction.
Features
- Oil resistant
- Flame-retardant
- UV radiation resistant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 1 | |
| Halogen free | No | |
| Core insulation material | PVC | |
| Standard number | UL, CSA | |
| Cable material | copper, bright | |
| Colour | black | |
| Product type | connection cable | |
| Conductor category | CL.5 = fine stranded | |
| Outer diameter | 7.8 mm | |
| Cable cross-section | 6.0 mm² | |
| Protective conductor available | No | |
| Test voltage | 4 kV | |
| Temperature range (active) | -5 °C to 90 °C | |
| Temperature range (unmoved) | -40 °C to 90 °C | |
| AWG cross-section | AWG 10 | |
| Rated voltage | 1000 V | |
| Rated voltage U0 | 600 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
