10747 | HELUKABEL
PVC control line JZ-500-ORANGE 3 G 2.5 mm², AWG 14, unshielded, orange, 10747
Unit Price (€ / mtr.)
2.2729 € *
Available in 5 Days: 1,500 mtr. - if ordered today
Control cable, 10747, HELUKABEL
The 10747 is a PVC control cable Used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use as a control cable acc. to EN 60204-1 or VDE 0113- 1. According to this standard, it is recommended that insulated conductors of interlocking power circuits supplied by an external power supply that remain live when the main switch is turned off, are marked in orange.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | PVC | |
| Core colour sequence | orange | |
| AWG cross-section | AWG 14 | |
| Outer diameter | 8.3 mm | |
| Test voltage | 4 kV | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Halogen free | No | |
| Temperature range (active) | -15 °C to 80 °C | |
| Shielding | unshielded | |
| Number of cores | 3 | |
| Colour | orange | |
| Material | PVC | |
| Protective conductor available | Yes | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Cable cross-section | 2.5 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Drag chain suitable | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
