10620 | HELUKABEL
PVC control line JZ-600 / OZ-600 4 x 1.0 mm², AWG 18, unshielded, black, 10620
Unit Price (€ / mtr.)
1.8326 € *
Available in 5 Days: 900 mtr. - if ordered today
Control cable, 10620, HELUKABEL
Wiring cable for measuring and controlling purposes in tool machinery, conveyor belts and production lines, for plant installations, air conditioning and in steel production plants and rolling mills. Suitable for installation for flexible use for medium mechanical stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms as well as outside (fixed installation). Is not suitable to be used as direct burria (suitable from an outer diameter of 18,0 mm for direct burial) or as underwater cable.
FEATURES
- Good chemical resistance
- Flame-retardant
- Oil-resistant
- UV-resistant
Technical Data
- Cable material: Copper, bright
- Test voltage: 4000 V
- Color: black
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage | 1 kV | |
| Version | control line | |
| Core colour sequence | black | |
| Colour | black | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Number of cores | 4 | |
| Conductor category | CL.5 = fine stranded | |
| Protective conductor available | No | |
| Core insulation material | PVC | |
| Outer diameter | 8.2 mm | |
| Shielding | unshielded | |
| Halogen free | No | |
| Test voltage | 4 kV | |
| Temperature range (active) | -15 °C to 80 °C | |
| AWG cross-section | AWG 18 | |
| Drag chain suitable | No | |
| Material | PVC | |
| Cable material | copper, bright | |
| Cable cross-section | 1.0 mm² | |
| Rated voltage U0 | 600 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
