10546 | HELUKABEL
PVC control line JZ-500-ORANGE 4 G 1.5 mm², AWG 16, unshielded, orange, 10546
Unit Price (€ / mtr.)
1.9278 € *
Available in 5 Days: 1,200 mtr. - if ordered today
Control cable, 10546, HELUKABEL
The 10546 is a PVC control cable Used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use as a control cable acc. to EN 60204-1 or VDE 0113- 1. According to this standard, it is recommended that insulated conductors of interlocking power circuits supplied by an external power supply that remain live when the main switch is turned off, are marked in orange.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Drag chain suitable | No | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Halogen free | No | |
| Number of cores | 4 | |
| Core insulation material | PVC | |
| Outer diameter | 7.6 mm | |
| Version | control line | |
| Cable material | copper, bright | |
| Temperature range (active) | -15 °C to 80 °C | |
| Rated voltage | 500 V | |
| Protective conductor available | Yes | |
| Test voltage | 4 kV | |
| Material | PVC | |
| Conductor category | CL.5 = fine stranded | |
| AWG cross-section | AWG 16 | |
| Shielding | unshielded | |
| Colour | orange | |
| Core colour sequence | orange | |
| Rated voltage U0 | 300 V | |
| Cable cross-section | 1.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
