10374 | HELUKABEL
PVC control line JZ-500 black 4 G 2.5 mm², AWG 14, unshielded, black, 10374
Unit Price (€ / mtr.)
3.8318 € *
Available in 5 Days: 1,100 mtr. - if ordered today
PVC Control cable, 10374, HELUKABEL
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines, conveyor belts, assembly lines, plant engineering, AC technology, steel production and other manufacturing environments.
FEATURES
- Good chemical resistance
- Power Chain
- Oil-resistant
- Cadmium-free
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: gray
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 4 | |
| Drag chain suitable | No | |
| Core insulation material | PVC | |
| Protective conductor available | Yes | |
| Halogen free | No | |
| Standard number | VDE | |
| Test voltage | 4 kV | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Colour | black | |
| Outer diameter | 9.2 mm | |
| Cable material | copper, bright | |
| Temperature range (active) | -15 °C to 80 °C | |
| Material | PVC | |
| AWG cross-section | AWG 14 | |
| Rated voltage U0 | 300 V | |
| Core colour sequence | black | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V | |
| Version | control line | |
| Cable cross-section | 2.5 mm² | |
| Shielding | unshielded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
