10360 | HELUKABEL
PVC control line JZ-500 black 7 G 1.0 mm², AWG 18, unshielded, black, 10360
Unit Price (€ / mtr.)
3.2368 € *
Available in 5 Days: 1,400 mtr. - if ordered today
Connection cable, 10360, HELUKABEL
The 10360 is a PVC connection cable used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, as well as outdoors. May not be laid directly in soil or water. Used as a connection and control cable in machine and plant construction, in machine tools, production lines, assembly lines and conveyor belts.
Features
- UV resistant
- For outdoor use
- Largely oil resistant
- Versatile use in many industries, particularly in machine and plant construction
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Outer diameter | 8.1 mm | |
| Rated voltage | 500 V | |
| Halogen free | No | |
| Material | PVC | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Version | control line | |
| Number of cores | 7 | |
| Core insulation material | PVC | |
| Protective conductor available | Yes | |
| AWG cross-section | AWG 18 | |
| Temperature range (active) | -15 °C to 80 °C | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Colour | black | |
| Cable cross-section | 1.0 mm² | |
| Drag chain suitable | No | |
| Conductor category | CL.5 = fine stranded | |
| Test voltage | 4 kV |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
