10018 | HELUKABEL
PVC control line JZ-500 / OZ-500 21 G 0.5 mm², AWG 20, unshielded, gray, 10018
Unit Price (€ / mtr.)
4.2840 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
428.40 € *
Price list
Quantity
Price per unit*
100 mtr.
4.2840 €
500 mtr.
4.0222 €
*incl. VAT plus shipping costs
Subject to prior sale
Connection cable, 10018, HELUKABEL
The 10018 is a PVC connection cable used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use. Used as a connection and control cable in machine tools, assembly lines and conveyor belts, production lines, in plant construction, air-conditioning technology, in smelters and steel mills. Select PVC compounds guarantee good flexibility, efficient and quick installation.
Features
- Largely oil resistant
- For selected torsion applications
- Conditionally suitable for drag chains
- Conditionally torsional
- Versatile use in many industries, particularly in machine and plant construction
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 20 | |
| Core insulation material | PVC | |
| Temperature range (active) | -15 °C to 80 °C | |
| Test voltage | 4 kV | |
| Colour | gray | |
| Halogen free | No | |
| Number of cores | 21 | |
| Shielding | unshielded | |
| Outer diameter | 11.3 mm | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Material | PVC | |
| Rated voltage U0 | 300 V | |
| Protective conductor available | Yes | |
| Rated voltage | 500 V | |
| Drag chain suitable | No | |
| Product type | control line | |
| Cable material | copper, bright | |
| Cable cross-section | 0.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
