97529 | HELUKABEL

Cable gland, M20, 24 mm, Clamping range 6 to 12 mm, IP68/IP69K, natural, 97529

Order No.: 93F7941
EAN: 4060892364587
MPN:
97529
Series: HSK-PVDF
97529 HELUKABEL Cable Glands Image 1
97529 HELUKABEL Cable Glands Image 2
Image may differ
Unit Price (€ / pc.)
4.8552 € *
Available in 5 Days: 500 pcs. - if ordered today
Total Price:
242.76 € *
*incl. VAT plus shipping costs
Subject to prior sale
50 pcs.
4.8552 €

Cable gland, 97529, HELUKABEL

The 97529 is a PVDF cable gland for use in the chemical industry, at high temperatures, under longterm UV exposure. The cable gland to meet stringent requirements in technology.

Features

  • Optimum strain relief through clamping lamella
  • Easy to assemble, time and cost savings
  • Watertight, dust-tight
  • Large clamping areas
  • Large temperature range
Technical specifications
Colour natural
Degree of protection (IP) IP68/IP69K
max. clamping range 12 mm
Product type cable gland
min. operating temperature -35 °C
Material PVDF
spanner size 24 mm
max. operating temperature 150 °C
min. clamping range 6 mm
Thread size M20
Logistics
Customs tariff number 39269097
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
