93926 | HELUKABEL

Cable gland, M25, 29 mm, Clamping range 11 to 17 mm, IP66/IP68, dark gray, 93926

Order No.: 93F7104
EAN: 4060892348501
MPN:
93926
Series: HELUTOP HT
93926 HELUKABEL Cable Glands
Image may differ
Unit Price (€ / pc.)
0.7378 € *
Available in 5 Days: 1,500 pcs. - if ordered today
Total Price:
36.89 € *
Price list
Quantity
Price per unit*
50 pcs.
0.7378 €
100 pcs.
0.6902 €
*incl. VAT plus shipping costs
Subject to prior sale

Cable gland, 93926, HELUKABEL

The 93926 cable gland has an optimum strain relief through clamping lamella. This product is easy to to assemble, time and cost saving.

Features

  • Watertight, dust-tight
  • With vibration protection
  • Large clamping area
  • Phosphor-free
  • Silicone-free
  • Cadmium-free

Applications

  • Machine and plant construction
  • Automation technology
  • Vehicle construction and shipbuilding
  • Railway technology
  • Installation technology
  • Control cabinet construction
  • Robotics
Technical specifications
Filter Property Value
max. operating temperature 100 °C
spanner size 29 mm
Thread size M25
Degree of protection (IP) IP66/IP68
Product type cable gland
Material PA
max. clamping range 17 mm
min. operating temperature -20 °C
min. clamping range 11 mm
Colour dark gray
Logistics
Property Value
Customs tariff number 39174000
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
