93872 | HELUKABEL
Cable gland, PG7, 15 mm, Clamping range 3 to 6.5 mm, IP66/IP68, black, 93872
Unit Price (€ / pc.)
0.4760 € *
Standard delivery time from the manufacturer is: 6 Weeks
Cable gland, 93872, HELUKABEL
The 93872 cable gland has an optimum strain relief through clamping lamella. This product is easy to assemble, time and cost savings.
Features
- Phosphor-free
- Silicone-free
- Cadmium-free
- Watertight, dust-tight
- Große Klemmbereiche
- With anti-kink spiral for mobile use
Applications
- Machine and plant construction
- Robotics
- Automation technology
- Vehicle construction and shipbuilding
- Railway technology
- Installation technology
Technical specifications
| spanner size | 15 mm | |
| Product type | cable gland | |
| Degree of protection (IP) | IP66/IP68 | |
| max. clamping range | 6.5 mm | |
| min. clamping range | 3 mm | |
| Material | PA | |
| Thread size | PG7 | |
| Colour | black | |
| max. operating temperature | 100 °C | |
| min. operating temperature | -20 °C |
Download
Logistics
| Customs tariff number | 39174000 |
Compliance
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
