904494 | HELUKABEL

Pressure screw, M12, 17 mm, IP68/IP69K, black, 904494

Order No.: 93F9280
EAN: 4060892375170
MPN:
904494
Series: PBE-K
904494 HELUKABEL Cable Glands
Image may differ
Unit Price (€ / pc.)
3.5105 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
351.05 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 pcs.
3.5105 €

Pressure balance element, 904494, HELUKABEL

The 904494 is a PA pressure balance element with semi permeable membrane that allows air flow but blocks moisture.

Applications

  • Machine and plant construction
  • Installation technology
  • Control cabinet construction
Technical specifications
Filter Property Value
spanner size 17 mm
max. operating temperature 105 °C
Colour black
Product type pressure screw
Degree of protection (IP) IP68/IP69K
min. operating temperature -20 °C
Thread size M12
Material PA
Logistics
Property Value
Customs tariff number 39269097
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
