903547 | HELUKABEL
Cable gland, M40, 46 mm, Clamping range 16 to 23 mm, IP66/IP68, dark gray, 903547
Unit Price (€ / pc.)
2.5466 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
50.93 € *
Price list
Quantity
Price per unit*
20 pcs.
2.5466 €
60 pcs.
2.3919 €
100 pcs.
2.2491 €
*incl. VAT plus shipping costs
Subject to prior sale
Cable gland, 903547, HELUKABEL
The 903547 cable gland cable gland has an optimum strain relief through clamping lamella. This product is easy to assemble, time and cost savings.
Features
- Phosphor-free
- Silicone-free
- Cadmium-free
- Watertight, dust-tight
- Große Klemmbereiche
- With anti-kink spiral for mobile use
Applications
- Machine and plant construction
- Robotics
- Automation technology
- Vehicle construction and shipbuilding
- Railway technology
- Installation technology
- Control cabinet construction
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | cable gland | |
| max. clamping range | 23 mm | |
| min. clamping range | 16 mm | |
| Colour | dark gray | |
| min. operating temperature | -20 °C | |
| Thread size | M40 | |
| spanner size | 46 mm | |
| max. operating temperature | 100 °C | |
| Degree of protection (IP) | IP66/IP68 | |
| Material | PA |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 39174000 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
