14310614402000 | Harting
PCB connector, 6 pole, pitch 3.5 mm, straight, green, 14310614402000
Order No.: 42F8799
EAN: 5713140206267
MPN:
14310614402000
har-flexicon 3,50 FSH-6 GN
Series: HAR-FLEXICON
Unit Price (€ / pc.)
3.1892 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
3.19 € *
Price list
Quantity
Price per unit*
1 pcs.
3.1892 €
10 pcs.
2.9750 €
50 pcs.
2.8917 €
100 pcs.
2.6418 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB connector, 14310614402000, Harting
The 14310614402000 is a horizontal PCB connector with screw termination and polyamide, polyphthalamide material.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact type | socket | |
| Pin number | 6 pole | |
| Grid | 3.5 mm | |
| Connection | screw connection | |
| Orientation | straight | |
| contact surface | silver-plated | |
| Rated voltage | 150 V | |
| Rated current | 10 A | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Colour | green |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
